lunar libration

After the recent lunar eclipse, I attempted to line up a before and after image, superimposing the full moon from the night before with the eclipsed moon just before sunrise, and found something odd: they don't match.  it wasn't just a matter of lining things up--which i can correct, or size--which i expected to be minor, but the surface of the moon itself appeared to have rotated:

lunar libration, full moon at sunset to eclipsed moon at sun rise 1/31/18

In a moment of doubt, i feared that a processing bug was creating horrific artifacts, since i know that the moon is tidally locked to the earth (it doesn't rotate, the same side always faces us).  then i recalled the term lunar libration, referring to minor rotation in the appearance of the moon relative to the earth.  a number of factors contribute to this, but the easiest to grasp is that as the earth rotates, the observer's location shifts.  in this case, viewing the moon at sunset and then sunrise, i had moved by the diameter of the planet earth, explaining why the moon appeared to rotate slightly.

Here's a really cool animation of lunar libration throughout a lunar month:

wikipedia lunar libration animation

as well as a more in depth explanation of the causes of lunar libration:

wikipedia

imaging details:

close up:

ZWO ASI120MC, Takahashi FS-60C at native F/5.9, 355 mm.

skywatcher star adventurer tracking mount

full moon .325 ms exposure 12 seconds captured at ~17 fps

eclipsed moon 152.6 ms exposure 68 second capture at 6 fps

13:24 UTS

1/31/2018

Eastbluff, CA

abell 33, the diamond ring nebula

Here's a spherical planetary nebula with a bright foreground star conveniently superimposed on the edge, providing the "diamond" for the ring:

Abell 33, the diamond ring nebula OIII RGB
click on image for full size

The small blue star in the center is the white dwarf creating the nebula.  A close up of the RGB version shows a hint of a second star to the lower right.  This is likely another superimposed star or a "visual double", as a double central star should (in theory with rare exception) create a bipolar, rather than a spherical nebula.

central star of Abell 33
RGB, upsampled 2x

apparently an open issue in astronomy is whether the percentage of planetary nebulae double central stars matches the percentage of doubles in the general stellar population.  there are several recent surveys which address this, and may confirm my supposition, but i don't have access to them.

The binary fraction of planetary nebula central stars - II. A larger sample and improved technique for the infrared excess search

The binary fraction of planetary nebula central stars: the promise of VPHAS+



The RGB image shows two other things:
1. how faint the nebula is, as it was barely detectable on the RGB image, requiring narrow band filters to bring it out.
2. how bright the "diamond" star is as it created a "bloom" (bright white artifact to the right of the brightest star).
should have shot the RGB unbinned to better resolve the central star and minimize blooming.

I did take a few trial Ha shots, but got only extremely faint signal in a circle, matching the OIII, but without detail.

Image details:
8" LX200R, SX Trius 694 binned x2 to 0.8"/px,
astrodon 3nm OIII, RGB E SERIES GEN-II
ASA DDM60
R 18x4 minutes, G 16x4 minutes, B 8x4 minutes
OIII 24x20 minutes.
4/14/17-5/1/17, bortle white skies
eastbluff, CA

super blue blood moon

here's the rising full moon on the evening of 1/30/18 followed by the setting super blue blood moon from the next morning (click on images for full size):

darker version with a bit more detail:

The full moon above is sharper than the eclipsed moon for several reasons:
1. the eclipsed moon was lower in the sky, therefore subject to more atmospheric turbulence
2. the faint eclipsed moon required longer exposure (500x), also increasing the effect of atmospheric turbulence.

shot this one in lazy mode.  my garage faces west, so i set up my imaging rig the night before, taking a quick image of the full moon to make sure everything was working.  then moved the equipment into the garage facing west, closed the door and went to bed.
got up and 5 AM, opened the door to my "observatory" and voila super blue blood moon over my neighbors house:

I'd checked the framing with the setting moon the week before.  this image took a fair amount of work in photoshop as the street lights gave the house a strange green tint. there was also star trailing evident over only 20 seconds (seen below), so i pasted the telescopic version over the moon image in the wide field DSLR image.

imaging details:

close up:

ZWO ASI120MC, Takahashi FS-60C at native F/5.9, 355 mm.
skywatcher star adventurer tracking mount

full moon .325 ms exposure 12 seconds captured at ~17 fps

eclipsed moon 152.6 ms exposure 68 second capture at 6 fps

13:24 UTS

wide field:

Nikon D-60, AF-S DX NIKKOR 55-300mm f/4.5-5.6G ED VR, f/5.6 55 mm 20" iso 400

1/31/2018

Eastbluff, CA
